In modern manufacturing, precise and efficient machining equipment is essential. We recommend this high-performance 4-axis CNC milling machine, designed to enhance your production efficiency and machining quality, suitable for various industries and applications.

 Working Principle

The 4-axis CNC milling machine utilizes a computer numerical control (CNC) system in conjunction with its mechanical structure to perform precise machining. The main working principles are as follows:

1. CNC Programming: Operators design parts using CAD/CAM software and generate the corresponding G-code, which instructs the machine on its operations.

2. Machine Movement: The machine's X, Y, and Z axes are responsible for linear movement of the workpiece, while the fourth axis (typically a rotary axis) allows for rotation during machining, enabling cuts from multiple angles. This design enhances the machine's capability to handle more complex geometries, increasing machining flexibility.

3. Tool Cutting: Under the command of the CNC system, the spindle rotates at a set speed, and the tool cuts along a predefined path. The spindle power (1.1 kW) and variable speed capability (300-3500 rpm) ensure efficient machining on various materials.

4. Real-Time Feedback: The machine is equipped with sensors and control systems that monitor the machining process in real time, ensuring the accuracy of tool position and cutting conditions, achieving high positioning accuracy (0.03 mm) and repeatability (0.02 mm).

5. Cooling System: During machining, the cooling system effectively reduces tool temperature, extends tool life, minimizes workpiece deformation, and ensures machining quality.

 Key Features:

- Flexible Machining Range: The X-axis travel is 300 mm, Y-axis is 175 mm, and Z-axis is 270 mm, suitable for processing various medium to small workpieces, widely applied in the automotive, aerospace, electronics, and mold manufacturing industries.

- Powerful Machining Capability: Maximum drilling/milling capacity of 13 mm, and milling tool diameter can reach 16 mm, capable of meeting diverse machining needs from simple parts to complex components.

- Precise Positioning: With positioning accuracy of up to 0.03 mm and repeatability of 0.02 mm, every machined part meets high standards, especially suitable for high-precision requirements in medical devices and aerospace components.

 User-Friendly Operation:

Equipped with the user-friendly XDBC818MD3 CNC system and handwheel operation, it is simple and intuitive, suitable for operators of various skill levels. Additionally, the cooling system effectively extends tool life and reduces maintenance costs.

 Ideal Use Scenarios:

1. Automotive Manufacturing: Machining engine parts and body structure components, ensuring high precision and excellent surface finish.

2. Aerospace: Machining complex aviation parts that meet strict weight and strength requirements, ensuring safety and reliability.

3. Electronics Industry: Suitable for manufacturing circuit board supports and enclosures, supporting high-precision machining for miniaturized designs.

4. Mold Manufacturing: Efficiently machining core components of molds for quick delivery, helping clients shorten production cycles.

 Conclusion:

This 4-axis CNC milling machine is your ideal choice for boosting productivity and ensuring machining quality. Whether in batch production or customized machining, it can be your valuable ally. Contact us now for more information or to arrange a trial, and let us help you advance steadily in a competitive market!
