When selecting cutting tools for a small universal lathe, it is essential to consider factors such as the material being processed, the machining process, cutting conditions, and tool life. While small lathes are relatively simple machines, choosing the right tools is still crucial for improving machining efficiency, ensuring quality, and extending the lifespan of the equipment. Below is a guide to the principles and recommendations for selecting cutting tools for small universal lathes.

1. Material Selection

First, understanding the type of material to be processed is essential. The hardness, toughness, and cutting characteristics of different materials significantly influence the choice of tools. Common materials processed on lathes include:

• Steel materials (e.g., mild steel, alloy steel, stainless steel): These materials require tools with high hardness and wear resistance. Carbide tools (e.g., tungsten carbide, high-speed steel) are commonly used.

• Aluminum alloys and non-ferrous metals: Aluminum is relatively easy to machine, and carbide or coated tools are suitable.

• Plastics and soft materials: These materials are easier to cut and typically use high-speed steel or coated tools.

2. Selection of Tool Material

The choice of tool material directly affects cutting efficiency, machining precision, and tool life. Common tool materials include:

• High-Speed Steel (HSS): HSS tools have high hardness and wear resistance, making them suitable for general metal cutting, especially at medium and low cutting speeds. However, they tend to overheat during high-speed cutting, leading to shorter tool life.

• Carbide (Cemented Carbide): Carbide tools are harder and more wear-resistant than HSS, suitable for high-speed cutting, especially for materials with higher hardness (e.g., alloy steels, stainless steels). Carbide tools can also be coated to further improve wear resistance.

• Ceramic Tools: Ceramic tools have extreme hardness and excellent heat resistance, making them ideal for machining hard materials. However, due to their brittleness, their use is more specialized.

• Coated Tools: Coatings can significantly improve the wear resistance, heat resistance, and corrosion resistance of tools. Common coatings include TiN, TiAlN, and CVD coatings. Coated tools have longer lifespans and improve cutting performance.

3. Selection of Tool Type

There are various types of tools used on a small universal lathe, and the choice depends on the specific machining requirements. Here are some common tool types and their applications:

• Turning Tools (External Turning Tools, Internal Turning Tools): These are the basic tools used for turning operations. External turning tools are used for machining the outer diameter, while internal turning tools are used for boring inner holes. For external turning, a standard 90-degree turning tool is often used. Internal turning tools are typically formed as curved or ring-shaped tools to handle internal bores.

• Finishing Tools (Fine Turning Tools): These tools are used when high precision and surface finish are required. Fine turning tools typically have smaller cutting edges, making them suitable for precision machining.

• Cutoff Tools: These tools are used to cut workpieces, especially when separating the workpiece from bar stock. Cutoff tools have special shapes and angles designed to ensure smooth cutting and reduce deformation during the process.

• Chamfering and Radius Tools: These tools are used to chamfer or round the edges of a workpiece. Chamfering tools have a specific angle that helps remove burrs created during machining, ensuring better workpiece quality.

• Threading Tools: Threading tools are specialized tools for cutting threads. These can be external threading tools or internal threading tools, designed to meet various thread standards, including metric, imperial, and specialized thread types.




•

4. Selection of Tool Geometry

The geometry of a cutting tool has a significant impact on machining performance and tool life. Common tool angles include:

• Rake Angle: A larger rake angle reduces cutting forces and improves surface finish but decreases tool life. A smaller rake angle, however, increases tool life and is suitable for machining harder materials.

• Relief Angle: The relief angle affects tool clearance and cutting efficiency. A larger relief angle reduces cutting forces, but excessive relief can weaken the tool.

• Side Cutting Edge Angle: This angle influences the contact area between the tool and the workpiece. A smaller side cutting edge angle can lead to unstable cutting, while a larger angle might reduce cutting efficiency.

5. Selection of Cutting Conditions

On small universal lathes, cutting conditions directly influence machining quality and efficiency. The main cutting parameters include cutting speed, feed rate, and cutting depth.

• Cutting Speed: Small lathes generally have lower spindle speeds, so tools need to be selected for lower-speed cutting. Carbide and coated tools can maintain good performance at low speeds.

• Feed Rate: The feed rate should be adjusted based on the material being cut and the tool’s capability. Harder materials usually require lower feed rates to prevent excessive wear and tear on the tool.

• Cutting Depth: Excessive cutting depth can put undue stress on the tool, making the cutting process unstable. Typically, shallow cuts are recommended to improve cutting stability and tool longevity.

6. Tool Management and Maintenance

Proper management and maintenance of cutting tools are essential to ensure the lathe operates smoothly and machining efficiency is optimized. Regular checks of tool wear are necessary, and tools should be replaced or re-sharpened promptly to prevent degradation in machining quality. Keeping tools clean and free from chips can also extend their service life.

7. Conclusion

Although small universal lathes are relatively simple machines, selecting the appropriate cutting tools remains a critical factor in improving machining efficiency, ensuring quality, and extending tool life. By choosing the right tool material, tool type, and cutting parameters based on the specific machining requirements, significant improvements in machining performance and tool longevity can be achieved. Proper tool management, along with routine maintenance, ensures that both machine and tools operate efficiently, reducing production costs and enhancing overall productivity.
